Stainless Steel 304 DN80 Firefighting Monitor For Fire Protection
Description Of Fire Fighting Monitors
Fire Fighting Monitors has the characteristics of adjustable flow,
long range, multi-function, small volume and good performance, and
it is the site management of conventional fire trucks, oil tankers,
wharfs, etc. The mobile fire-fighting gun is mainly composed of
mobile site, mop, intake pipe, rotary body and gun head, and it has
two 65-diameter intakes. Under the same pressure, the flow of the
water-gun can be adjusted, and with the infinite adjustment of the
direct current to 90 degree water mist jet can be implemented,
which can result in better fire-fighting and cooling effect. It has
good fire extinguishing performance. The gun is suitable for
petrochemical enterprises, storage tanks, hangars, warehouses, port
terminals and other places, and it is also an ideal vehicle-mounted
fire gun for fire trucks.
Feature Of Fire Fighting Monitors
* Compatible with Foam Tube
* Simple to operate
* Automatic Nozzle
* Easy to service and repair.
* Stainless Steel 304 Construction
* Wireless electric remote control drive
* Stable performance, flexible operation and easy to maintenance.
* Low inlet pressure
* Large flow and range far
* Light weight and small volume.
* It can spray in close distance, remote monitoring.
* It can spray water column and water mist use different gun head.
Function Introduction Of Fire Fighting Monitors
1. Straight stream & spray: rotating gun head, water flow from
spray to straight stream;
2. The rise and fall: rotary swing handle, barrels rises and falls
from 30 ° ~ 70 °;
3. Left and right: manual swing in the desired direction;
4. Control distance: 0~150m;
5. Three modes: remote control, gun position control and manual
operation.
Specification Of Fire Fighting Monitors
| Water Flow Rates | 20L/S,30L/S,40L/S,50L/S,60L/S,70L/S,80L/S |
| Jetting Range | From 48 meters to 80 meters,it depends on the working pressure |
| Working Pressure | 0.8 Mpa,0.9Mpa,1.0Mpa,1.2Mpa |
| Connection type | Flange type |
| Body Material | Stainless Steel 304,Cast iron,Ductile iron |
| Sealing Material | NBR |
| Painting Color | Red,RAL3000 |
| Flange Size | 80mm,100mm |
| Applicable Medium | Water,Foam,foam mixture,such as AFFF3%,AFFF6% |
| Updown Turning angle | >70 degree |
| Horizontal Turning Angle | >180 degree |
| Installation Type | Fixed type |
| Working Type | Manual type |
| Manufacture Standard | GB50338-2003 |
| Model Number | PS |
| Model | PS20 | PS30 | PS40 | PS50 | PS60 | PS70 | PS80 |
| Flow(L/S) | 20 | 30 | 40 | 50 | 60 | 70 | 80 |
| Working Pressure(Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.9 | 0.9 | 0.9 |
| Max Working Pressure(Mpa) | 1 | 1 | 1 | 1 | 1.2 | 1.2 | 1.2 |
| Flange Connection(mm) | DN80 | DN80 | DN80 | DN80 | DN100 | DN100 | DN100 |
| Water Jetting Range(m) | ≥ 48 | ≥ 55 | ≥ 60 | ≥ 65 | ≥ 70 | ≥75 | ≥80 |
| Horizontal Angle (Degree) | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 | 0-360 |
| Max angle of elevation (Degree) | 70 | 70 | 70 | 70 | 70 | 70 | 70 |
| Max Angle Of Depression (Degree) | -70 | -70 | -70 | -70 | -70 | -70 | -70 |
Application Of Fire Fighting Monitors
Fire water monitor is a fire fighting device which help to spray
water and suppress fire at a long distance. It’s widely used for
oil industrial, storage tank farm, hangar, warehouse, sea port,
garage and other areas. It’s also an ideal device for fire fighting
vehicle.
Fire & Rescue Services,Marine Sectors,Oil & Gas,Petrochemicals,Fuel
Storage Sites,Major Industrials,Aviation
FAQ
1. What is the minimum order quantity for your product?
The minimum order quantity is one set/set.Foam liquid is generally
1000 liters
2. Do you have your own factory manufacturer?
Yes, we have been a manufacturer for more than 20 years. Our main
products are foam fire extinguishing equipment, bladder storage
tank foam system, balanced pressure distribution system, etc. We
can provide a one-stop service including fire protection products.
3. What are your payment terms?
We accept wire transfer, letter of credit, Western Union, Paypal,
etc.
4. How long is the delivery time?
Usually about 15 days after payment, if you have custom or other
requirements for delivery time, you need to communicate again.
5. Can OEM be accepted?
Yes, we provide customized designs for customers.
Feel free to contact us!
